Take control. Controller options.
This range is compatible with the following controller options.
| Available in | Cooling Only - 2.5kW, 3.4kW, 5.0kW, 7.1kW, 8.5kW, 9.5kW |
| Refrigerant | R32 |
Key features
-
Apple-Catechin FilterFine dust, invisible mould spores and harmful microorganisms are absorbed onto the filter by static electricity and further growth is inhibited and deactivated by the polyphenol ingredient extracted from apples.
-
All DCWith All DC, electricity loss is decreased and power consumption reduced.
-
Auto RestartShould there be a temporary loss of power, the unit will automatically restart itself in the same operating mode, once the power is restored.
-
Auto Shut LouvreThe auto shut louvres close or open automatically when the unit stops or starts.
-
Automatic LouvreThe position of the louvres is set automatically to match the operating mode. It is also possible to adjust the louvres using the remote control.
-
Blue Fin Heat ExchangerCorrosion-resistance of the heat exchanger in coastal areas has been improved by blue fin treatment of the outdoor unit heat exchanger.
-
DRED Standard EquipmentA Demand Response Enabled Device (DRED) terminal is standard on all Comfort range outdoor units. This enables an energy provider to easily manage power consumption during peak usage periods to minimise impact on the network. Less
-
Economy ModeLimits the maximum operation current, and performs operation with the power consumption suppressed.
-
Filter SignSelect appropriate intervals for displaying the filter sign on the indoor unit according to the estimated amount of dust in the air of the room.
-
i-PAMi-PAM inverter technology enables high output and high efficiency performance.
-
Long-Life Ion Deodorisation FilterThe filter deodorises by powerfully decomposing absorbed odours using the oxidising and reducing effects of ion generated by the ultra-fine particle ceramic.
-
.png?sfvrsn=de64a3c_1)
Precise Temperature ControlThe remote control now allows you to set temperature in 0.5C increments, giving you better control of your comfort.
-
Program TimerThis timer allows selection of one of four options. ON, OFF, ON ––> OFF, or OFF ––> ON.
-
Powerful ModePowerful mode will operate the indoor unit fan and outdoor unit compressor at maximum operation to quickly make the room conditioned and comfortable.
-
On-Off TimerON-OFF timer can be set to operate once every 24 hours.
-
Super Quiet ModeThe indoor units fan can operate at a low speed to produce quieter operation.
-
Sleep TimerThe micro-processor gradually changes the room temperature, allowing you to sleep comfortably at night.
-
Up/Down Swing LouvreThe up/down louvre automatically swings up and down.
-
Washable PanelDust that accumulates on the air conditioner can be easily cleaned with a damp cloth.
-
V-PAMv-PAM inverter technology increases the maximum output of the compressor significantly and enables high power and high efficiency.
What are other customers saying?
-
0.5°C IncrementsThe remote control now allows you to set temperature in 0.5°C increments, giving you a better control on your comfort.
-
Error Code DisplayError sign is shown on the wired remote controller display or the indicator lamps on the IR receiver unit.
-
Powerful ModeThis mode will operate the air conditioner at maximum capacity for 20 minutes, providing comfort faster than ever before.
Find the perfect model. Explore the Comfort Cooling range.
Technical Specifications
| Attribute | ASTH09CNCA 2.50kW(C) View model | ASTH12CNCA 3.40kW(C) View model | ASTH18CNTA 5.00kW(C) View model | ASTH24CNTA 7.10kW(C) View model | ASTH30CNTA 8.50kW(C) View model | ASTH34CNTA 9.50kW(C) View model |
|---|---|---|---|---|---|---|
|
Operation Type
|
Cooling Only | Cooling Only | Cooling Only | Cooling Only | Cooling Only | Cooling Only |
|
Power Source
V/Ph/Hz
|
230 / 1 / 50 | 230 / 1 / 50 | 230 / 1 / 50 | 230 / 1 / 50 | 230 / 1 / 50 | 230 / 1 / 50 |
|
Cooling Capacity
kW (Rated (Min - Max))
|
2.50 (0.9 - 3.7) | 3.40 (0.9 - 3.7) | 5.00 (0.9 - 5.6) | 7.10 (1 - 8) | 8.50 (2.9 - 10.5) | 9.50 (2.9 - 11.2) |
|
Input Power Cooling
kW (Rated (Max))
|
0.59 (1.14) | 0.96 (1.27) | 1.44 (1.74) | 2.2 (3) | 2.3 (3.45) | 2.83 (3.85) |
|
EER Cooling
kW/kW
|
4.24 | 3.54 | 3.47 | 3.23 | 3.7 | 3.36 |
|
Star Rating Cooling
(0-10) (Hot / Average / Cold)
|
5 / 4.5 / 4.5 | 4 / 3.5 / 4 | 3.5 / 3.5 / 3.5 | 3.5 / 3 / 3.5 | 4 / 4 / 4 | 3.5 / 3.5 / 3.5 |
|
Total Cooling Seasonal Performance Factor Residential
kW (Hot / Average / Cold)
|
6.538 / 6.121 / 6.486 | 5.537 / 5.239 / 5.605 | 5.395 / 5.122 / 5.491 | 5.143 / 4.897 / 5.288 | 5.773 / 5.501 / 5.895 | 5.235 / 5.005 / 5.383 |
|
Running Current
amps (Cooling)
|
3 | 4.8 | 6.4 | 9.6 | 10.2 | 12.4 |
|
Moisture Removal
l/hr
|
1 | 1.2 | 2.3 | 3.2 | 4.4 | 4.9 |
|
Indoor Sound Pressure Cooling
dBA (High / Quiet)
|
46 / 22 | 40 / 20 | 46 / 27 | 50 / 31 | 51 / 32 | 51 / 32 |
|
Outdoor Sound Pressure
dBA (Cooling)
|
49 | 50 | 49 | 55 | 53 | 53 |
|
Outdoor Sound Power
dBA
|
62 | 65 | 61 | 67 | 67 | 67 |
|
Air Circulation (Indoor - High Fan) Cooling
l/sec
|
175 | 194 | 225 | 336 | 381 | 381 |
|
Indoor Unit Dimensions
mm (Height x Width x Depth)
|
270 x 784 x 224 | 270 x 834 x 215 | 270 x 834 x 232 | 280 x 980 x 240 | 340 x 1150 x 280 | 340 x 1150 x 280 |
|
Indoor Unit Weight
kg
|
8.00 | 9.50 | 11.00 | 12.50 | 16.50 | 16.50 |
|
Outdoor Unit Dimensions
mm (Height x Width x Depth)
|
541 x 663 x 290 | 541 x 663 x 290 | 542 x 799 x 290 | 632 x 799 x 290 | 788 x 940 x 320 | 788 x 940 x 320 |
|
Outdoor Unit Weight
kg
|
25.00 | 25.00 | 37.00 | 42.00 | 52.00 | 52.00 |
|
Piping Connects
mm Ø (Liquid / Gas)
|
6.35 / 9.52 | 6.35 / 9.52 | 6.35 / 12.7 | 6.35 / 12.7 | 9.52 / 15.88 | 9.52 / 15.88 |
|
Pipe Length
m (Max (Precharged))
|
20 (15) | 20 (15) | 25 (15) | 30 (15) | 50 (20) | 50 (20) |
|
Max Height Difference
m
|
15 | 15 | 20 | 25 | 30 | 30 |
|
Operation Range Cooling
°CDB (Min to Max)
|
10 to 50 | 10 to 50 | 10 to 50 | 10 to 50 | 10 to 50 | 10 to 50 |
|
Refrigerant Type
|
R32 | R32 | R32 | R32 | R32 | R32 |
|
Refrigerant Amount
g
|
- | - | - | - | - | - |
